Vue form components with server side validation in mind

Vue form components with server side validation in mind

FormVuelar

FormVuelar is a set of predefined vue form components which are designed to automatically display errors coming back from your backend. It works out of the box with the error message bag that is returned by Laravel when submitting an ajax form.

Features

- Works out of the box with Laravel
- Axios integration
- File upload support including process indicator
- Dropzone with image preview (inspired by FilePont)
- Display validation error messages from error response

Getting Started

npm install formvuelar --save

Available Components

The following components are shipped with FormVuelar:

Name Description Import Name
<fvl-form /> Form wrapper element import { FvlForm } from 'formvuelar'
<fvl-input /> Input field import { FvlInput } from 'formvuelar'
<fvl-textarea /> Text area field import { FvlTextarea } from 'formvuelar'
<fvl-radio /> Radio input field import { FvlRadio } from 'formvuelar'
<fvl-checkbox /> Check box input field import { FvlCheckbox } from 'formvuelar'
<fvl-select /> Select input field import { FvlSelect } from 'formvuelar'
<fvl-file /> File input field import { FvlFile } from 'formvuelar'
<fvl-multi-file /> Multi file input field import { FvlMultiFile } from 'formvuelar'
<fvl-dropzone /> Dropzone field import { FvlDropzone } from 'formvuelar'
<fvl-submit /> Submit button import { FvlSubmit } from 'formvuelar'

Components Props & Events

Name Prop/Event Type Default Possible values Notes
fvl-form :method String 'post' get|post|put|patch|delete
:data Object {} {}
:url String null
:multipart Boolean false true|false
@success Function axios response
@error Function axios error response
@upload-progress Function 0-100
fvl-input :value.sync Data '' form.name
:id String null
:name String ''
:label String null
:type String 'text'
:placeholder String null
:autocomplete String null
:field-class String null
:min Number null
:max Number null
:size Number null
:step Number null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
:pattern String null regex
fvl-textarea :value.sync Data '' form.about
:id String null
:name String ''
:label String null
:placeholder String null
:autocomplete String null
:field-class String null
:cols Number null
:maxlength Number null
:rows Number null
:wrap Boolean null hard|soft
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
:pattern String null regex
fvl-select :selected.sync Data null form.favoriteColor
:options Object {} {'key': 'value', ...}
:id String null
:name String ''
:label String null
:allow-empty Boolean false true|false
:placeholder String null
:autocomplete String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-radio :checked.sync Data null form.newsletter
:options Object {} {'key': 'value', ...}
:id String null
:name String ''
:label String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-checkbox :checked.sync Data null form.terms
:id String null
:name String ''
:label String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-file :file.sync Data null form.avatar
:id String null
:name String ''
:label String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-multi-file :files.sync Data null form.gallery
:id String null
:name String ''
:label String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-dropzone :files.sync Data null form.media
:id String null
:name String ''
:label String null
:required Boolean false true|false
:readonly Boolean false true|false
:disabled Boolean false true|false
fvl-submit :loader Boolean false true|false
:disabled Boolean false true|false

Basic Form Template

Create a form and sent it via post request to your server.

<!-- form wrapper -->
<fvl-form method="post" :data="form" url="/create">

    <!-- Text input component -->
    <fvl-input
        :value.sync="form.fullname"
        label="Full Name"
        name="fullname"
    />

    <!-- Textarea component -->
    <fvl-textarea
        :value.sync="form.bio"
        label="Bio"
        name="bio"
    />

    <!-- Radio component with options -->
    <fvl-radio
        :checked.sync="form.pet"
        :options="{'cat': 'Cat', 'dog': 'Dog'}"
        label="Favorite pet"
        name="pet"
    />

    <!-- Submit button -->
    <fvl-submit>Validate</fvl-submit>

</fvl-form>

The form object you pass into the form component above would look like this:

import { FvlForm, FvlInput, FvlTextarea, FvlRadio, FvlSubmit } from 'formvuelar'
...
    components: {
        FvlForm,
        FvlInput,
        FvlTextarea,
        FvlRadio,
        FvlSubmit,
    },
    data() {
        return {
            form: {
                fullname: '',
                bio: '',
                pet: ''
            },
        ...

Error Response

The response from your Backend should contain a Json error object and have a status of 422 in order to show the error messages below the input fields. This response format is default for Laravel and will work out of the box.

{
  "message": "The given data was invalid.",
  "errors": {
    "field-1": [
      "Error 1",
      "Error 2"
    ],
    "field-2": [
      "Error 1",
      "Error 2"
    ]
  }
}

Client side validation

You can still use the default HTML5 validation rules for all input fields like 'accept' and 'required' for file inputs:

    <fvl-file
        label="Avatar"
        name="avatar"
        :file.sync="form.avatar"
        accept="image/*"
        required
    />

Styling

The styling is totally up to you. All components have their own classes so you have full control over the look and feel of every component.

Every component is wrapped with a div and the corresponding class .fvl-{type}-wrapper. Labels have a class name of .fvl-{type}-label. The field itself has a class name of .fvl-{type}

Example classes of the text input component (using Tailwind)

.fvl-input-wrapper {
    @apply p-2;
}
.fvl-input-label {
    @apply block uppercase tracking-wide text-grey-darker text-xs font-bold mb-2;
}
.fvl-input {
    @apply appearance-none block w-full bg-grey-lighter text-grey-darkest border border-grey-lighter rounded py-3 px-4 leading-tight;
}

I'm using Tailwind CSS for the examples. Feel free to use the predefined css component classes for your own projects.

TODO

- Advanced select component with search and remote source option
- Tags component
